Detachable Container House
Solar Panel Detachable Container House
Off-grid solar power, lower running costs Bolted frame, 4-hour assembly
| External Dimensions(mm) | 5950L*3000W*2800H |
| Internal Dimensions(mm) | 5770L*2820W*2500H |
| Total Weight (kg) | 1000 |
| Container Loading | 15units/40HC |
| Installation | 4 workers, 1 set installed in 4 hours |
Product Overview
The FONZE HOUSE Solar Panel Detachable Container House combines our proven detachable modular structure with a roof-mounted solar photovoltaic system, delivering a building that generates its own clean electricity. Lighting, ventilation, small appliances and charging points can run off-grid, cutting diesel generator use and daily energy costs on remote sites.
The unit is built on a bolted galvanized steel frame with double-layer rock wool sandwich panels. Every component is factory pre-cut, drilled and numbered for welding-free on-site assembly — 4 workers can install one set in about 4 hours. All parts fit standard containers, keeping international freight costs low.
The solar system consists of roof-mounted PV panels, a charge controller and battery storage, with panel quantity and battery capacity configurable to match local sunshine conditions and power demand. The interior layout, doors, windows and electrical standard are fully customizable.
Ideal for construction site offices, labor camps, energy and mining projects, emergency relief stations and any location where grid power is unavailable or expensive.
Solar Panel + Energy Storage System
Structure & Materials
| Section | Item | Specification |
|---|---|---|
| Frame | Top Beam | 2 × 5.635m + 2 × 2.68m (pcs) |
| Frame | Bottom Beam | 2 × 5.63m + 2 × 2.68m (pcs) |
| Frame | Column | 4 × 2.47m (pcs) |
| Frame | Hinge Corner | 8 pcs |
| Frame | Chassis Purlin Reinforcement | 4 × 2.97m + 5 × 2.97m + 2 × 0.6m (pcs) |
| Frame | Roof Purlin Reinforcement | 5 × 2.9m (pcs) |
| Frame | Surface Treatment | Electrostatic spray coating + baking finish (top/bottom beams, vertical/corner columns) |
| Wall | Double-Layer Rock Wool Panel | 50 series, 50 kg/m² surface density, double-sided film, 16.5 × 2.5m (pcs) |
| Roof | Roof Sheet | 1000 pressed steel plate, 3 × 6m (pcs) |
| Roof | Ceiling Sheet | 831 pressed steel plate, 7 × 2.68m (pcs) |
| Floor | Magnesium Board / Cement Fiber Board | 5 × 1157×2840mm (pcs) |
| Door & Window | Entrance Door | Steel door with handle (lock included), 970×1970mm |
| Door & Window | Window | 5+9A+5 double tempered glass with screen, 2 × 970×1040mm (pcs) |
| Solar System | PV Panels | Roof-mounted solar photovoltaic panels, quantity configurable |
| Solar System | Power Storage | Charge controller + battery storage, capacity per project power demand |
| Hardware | Corner Fittings | Colored steel corner fittings, 1 set (top corner fittings for columns) |
| Hardware | Insulation & Adhesives | Glass wool rolls + all screws, structural adhesive |
Customization Options
| Category | Available Options |
|---|---|
| Door | Broken-bridge aluminum swing door with side window / Broken-bridge aluminum double swing door / Broken-bridge aluminum sliding door / Ti-Mg alloy sliding door / KFC-style aluminum door / Standard steel door / Broken-bridge aluminum double-leaf door |
| Window | Broken-bridge aluminum sliding window / Broken-bridge aluminum casement window / Aluminum sliding window / Aluminum casement window / Broken-bridge aluminum awning window / uPVC casement window / Broken-bridge aluminum double-glazed casement window |
| Socket | US standard (Type A/B) / AU/NZ standard (Type I) / CN standard (5-hole) / EU standard (Type F/Schuko) / IT standard (Type L) / IL standard (Type H) / UK standard (Type G) / IN/ZA standard (Type D/M) / US UL-certified wire socket |
| Floor | White pine vinyl sheet / Grey pear wood vinyl sheet / Palm wood vinyl sheet / Light grey vinyl sheet / Engineered wood flooring / SPC rigid vinyl plank / Kitchen wall cabinet |
| Bathroom | Wet & dry separated bathroom / Glass shower enclosure / Vanity cabinet with mirror / AU-standard plumbing fittings / Ceramic floor tile |
Solar Power System
Roof-mounted PV panels with battery storage provide clean off-grid electricity, cutting generator and grid costs
Factory Direct Price
No middlemen, save 15-20% compared to trading companies
Modular Assembly & Disassembly
Bolt-connected design enables fast assembly and easy relocation
Detachable Container Loading
Detachable components fit standard containers, 15 units per 40HC
Durable Steel Structure
Galvanized steel frame with anti-corrosion treatment, 20+ years service life
Customizable Design
Size, color, door/window, solar capacity and electrical standard customizable
Fast Delivery
Standard products ready in 10-15 working days
Quality Certification
ISO 9001 / CE / SGS certified
Packaging & Shipping
Flat-pack components loaded into container
Secured with steel straps for sea freight
Ready for port delivery and global shipping
Quality inspection before shipment
Shipping & Delivery
| Item | Standard Model | Customized Model |
|---|---|---|
| Production Time | 5-15 days | 10-25 days |
| Sea Freight | 10-25 days | 15-35 days |
| Port of Loading | Tianjin (default), optional: Qingdao / Shanghai / Guangzhou / Shenzhen | |
Installation Support
Each shipment includes detailed installation manuals with step-by-step instructions. We also provide video guides and remote technical support to ensure smooth on-site assembly. For large orders, we can arrange on-site installation guidance by our experienced engineers.On-site Installation Service
- Available for domestic and international projects
- Additional costs: engineer visa, travel expenses, accommodation, and installation guidance fees
- For overseas projects: we typically provide remote technical guidance while local workers complete the installation
Foundation Requirements
- Flat and level ground surface is required
- Brick leveling pads are also acceptable as foundation
- No complex foundation work needed for most models
Unloading & Handling
- Forklift is recommended for efficient unloading
- Manual unloading is possible when forklift is not available
- Please ensure adequate space and equipment at the delivery site
